Gears & splines
Gears and splines, cut without sending the part out.
Gear work normally means a second supplier, a second setup and a datum you have to re-establish. We cut gears and splines on the Multus — by skiving, broaching or gear milling — in the same clamping as the journals, faces and bores they have to run true to.
- Skiving · broaching · gear milling
- Tolerances to ±0.0001″
- Minimum order 1 part
- 2-day rush available
- Livermore, CA
Specifications
The numbers.
| Processes | Gear skiving · gear broaching · gear milling |
|---|---|
| Machines | 2 × Okuma Multus U3000 1SW1000 — C axis 360° at 0.0001°, live tooling |
| Internal splines | Cut in the bore in the same setup as the OD and faces |
| Max part envelope | Ø650 mm (25.59″) × 1,100 mm (43.31″) |
| Concentricity | Gear or spline and its bearing journals cut in one clamping |
| Inspection | On-machine Renishaw probing, plus Zeiss CMM for final dimensional work |
| Tolerances | To ±0.0001″ on the Multus where the print calls for it |
| Materials | Aluminum alloys · stainless steels · carbon and alloy steels · titanium · brass, bronze and copper · high-temperature alloys including Waspaloy and single-crystal · engineering plastics |
| Minimum order | 1 part — we take one-offs |
| Lead time | Quoted per job. 2-day turnaround available for hot projects. |
| File formats | STEP, IGES, Parasolid, native Fusion 360 or SOLIDWORKS, plus PDF / DXF prints |
Typical work
Parts we make this way.
If yours isn't on the list, it doesn't mean we can't — it means send the model and we'll tell you straight.
- Splined shafts
- Internal splines in pulleys
- Splined and keyed bores
- Spur gears
- Serrations and toothed features
- Sprockets and timing profiles
- Gear blanks finished complete
- Shafts with gear and journal features together
Other services
Not quite it?
Parts rarely fit one category cleanly. We'll route your job to whichever machine holds it best — that's the advantage of having all of them under one roof.
Why it comes out right
What you actually get.
Concentric by construction
When the spline and the journals it must run true to are cut in the same clamping, concentricity is a property of the setup rather than something you inspect and hope for.
No gear-shop handoff
Sending a part out for gear work adds a supplier, a lead time and a re-fixturing. Cutting it here removes all three.
Skiving for internal forms
Power skiving cuts internal gears and splines continuously, using synchronised rotation between tool and workpiece — which is exactly what a C-axis mill-turn with live tooling is for.
Send us the model.
You'll get a straight answer on whether this is the right process for your part — including if it isn't.
